Introduction:
This device uses optical fiber transmission technology and standard SFP optical module to extend HDMI signal to 20km (single mode) with non-destructive, Using a single fiber bidirectional LC interface to transmit optical fiber lines is low cost and more stable signal transmission. Supports 4K@60Hz 4:4:4 HDR video transmission, it can extended output and an independent audio separation output, Suitable for professional settings including broadcast production, integrated conference systems, and HD surveillance applications.
Features:
* Support HDMI 4K@60Hz/ HDCP 2.2/2.3/ HDCP 1.4
HDMI Input and output resolution: The highest input resolution is 4096×2160@60Hz
Audio format: DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/ATMOS/PCM
* Support 7.1 channels
* Support 3.5mm stereo output;
Fiber transmission distance: Up to 20km
Fiber wave length: 1270/1330nm
* Supports HDR (HDR10/HDR10+/Dolby Vision/HLG);
* Support for ALLM;
* Complies with SFP+ MSA and SFF-8472&SFF-8431 standard protocols;
* Pure hardware design, plug and play, no additional software required.
The maximum operating current: 0.8A/5VDC (TX), 0.7A/5VDC (RX)
Operating Temperature range: (0℃~ +45℃)
Dimension (L x W x H): 89x49x20(mm)*2
Weight: 95g*2
