Features:
Support 4 HDMI inputs, 1 HDMI output ;
Support 4 channels HDMI signal screen segmentation;
Compatible with HDMI 2.0 and HDCP 1.4
Support input highest resolution up to 4K/30Hz;
Support Output resolution 4K@60Hz, 4K@30Hz, 1080P@60Hz, 1080P@30Hz;
Color format: RGB 4:4:4; YUV 4:4:4; YUV 4:2:2
Support 24/30/36 bit deep color;
Max bandwidth: 600MHz
Max baud rate: 18Gbps
Support IR control;
Support audio output format: PCM2.0 ;
Support standard AWG26 cable, input up to 10 meters, output up to 10 metres ;
Supports 1 way mouse and keyboard to control 4 ways PC host;
USB supports Windows, Linux, MAC OS and Android operation system, etc;
Plug and play;
Supports USB 2.0 Low speed (1.5Mb/s); Full speed(12Mb/s) ;
Maximum working currency: 0.8 A
Power adapter format: Input AC (50 hz, 60 hz) 100V to 240V; Output: 12V DC
Operating Temperature range: (10 ~ + 45 ℃)
Dimension: 226x105x24(mm)
Product net weight: 507g
